Xnova XTS 2618-1860kv 10P Var. C
Designed for extrem 3D , 320-360mm bladesize helicopter where highest power to weight ratio is important.
Slots & Poles 12n10p
Winding T 10D
rpm/V 1860
Volt (V) 10 / 22.2
Io(A) 2.5 / 4.2
Rm (mohm) 15
Weight (without connector) (g) 110
Body Length (no shaft) mm 38.1
Diameter (mm) 33
Shaft Length (mm) (Details pictures) A,B,C
Shaft Dia. (mm) C=3 / B=3
Mounting Holes CTC Distance (mm) 19*2 & 16*2
Mounting Screw M3x0.5
Max Eff. Curr. 40.82 / 78.84
Max Eff. 87.75 / 89.35
Kt (Nm/A 0.0051
Km (Nm/sqrt(w)) 0.0419
Max Continuous Power(Watts) 900
Peak Continuous Power(Watts) (2 sec) 1200
Max Continuous Current(Amps) 45
